i-box Lite - Top View Controls; Bottom View Features; Back View Ports

VOLUME
SNOOZE
SLEEP/DIMMER
1
2
4
7
3
5
6
8
USB 5V
DC 5V
10 11
12
13 14
9
Back ViewBottom View
Top View
Top View
01. Volume – / Alarm key
02. Volume + / Clock key
03. Mode / Alarm Off key
04. Previous key
05. Next key
06. Preset key
07. Snooze/Sleep/Dimmer key
08. Display
Bottom View
09. Backup Battery Compartment
Back View
10. Bass Reector port
11. Speaker
12. Wire Antenna
13. USB 5V Output port
14. DC 5V IN port
Please make sure the antenna
12
is fully
extended for optimum reception when
listening to radio stations.
