User’s Manual
SPECIFICATIONS-iH283
Driving system TFT Color LCD
Size 70cm / 27.5” Diagonal
LCD Panel
Pixel pitch 0,309mm(H) x 0,309mm(V)
H-Frequency 24KHz – 80KHz
Video
V-Frequency 56 – 75Hz
Display Colors 16.7M Colors
Max. Resolution 1920 x 1200 @60Hz
Plug & Play
VESA DDC2B
TM
ON Mode 90W (Typical)
Power Saving Mode ≤1W
Power consumption
OFF Mode ≤0.5W
Audio output Rated Power 2.0 W rms (Per channel)
Input Terminal
VGA
DVI
HDMI
Maximum Screen Size
Hor. : 593,28mm
Ver. : 370,8mm
Power Source 100~240V AC, 50~60Hz
Environmental
Considerations
Operating Temp:0° to 50°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 80%
Dimensions
652,7(W) x 523,29(H) x 254(D) mm
25,7 ”(W)×20,6 ”(H)×10 ”(D)
Weight (NW) 8.5 kg
*** The above specification is subject to actual product specification and is subject to change
without prior notice.
23
