User’s Manual
APPENDIX
SPECIFICATIONS-iH253
Driving system TFT Color LCD
Size 62,5cm / 24.6” Diagonal
LCD Panel
Pixel pitch 0,283mm(H) x 0,283mm(V)
H-Frequency 24KHz – 83KHz
Video
V-Frequency 56 – 75Hz
Display Colors 16.7M Colors
Max. Resolution 1920 x 1080 @60Hz
Plug & Play
VESA DDC2B
TM
ON Mode 50W (Typical)
Power Saving Mode ≤1W
Power consumption
OFF Mode ≤0.5W
Audio output Rated Power 2.0 W rms (Per channel)
Input Terminal
VGA
DVI
Maximum Screen Size
Hor. : 543,46mm
Ver. : 305,69mm
Power Source 100~240V AC, 50~60Hz
Environmental
Considerations
Operating Temp:0° to 50°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 80%
Dimensions
581,5 (W) x 433,4(H) x 200(D) mm
22,9 ”(W)×17,1 ”(H)×7,9 ”(D)
Weight (NW) 6.1 kg
*** The above specification is subject to actual product specification and is subject to change
without prior notice.
