5
Specifications
Transfer rate:
(sustained)
DVD-ROM Maximum 21,600 Kbytes/Sec.*
CD-ROM Maximum 6,000 Kbytes/Sec.*
* The data transfer rate may not be output due to disk
conditions (scratches, etc).
Access time:
(random average)
DVD-ROM 95 ms
CD-ROM 80 ms
Data buffer capacity:
512 Kbytes
Disk diameter:
12 cm (4.72”), 8 cm (3.15”)*
*8 cm disks cannot be used at upright position.
Audio output (Line):
0.7 Vrms ± 0.5 Vrms (at 10 KΩ load).
Power supply:
DC +12V, 1.6A (peak)
1.1A (normal)
DC +5V, 1.6A (peak)
1.1A (normal)
External dimensions:
148 (W) X 42.3 (H) X 208.5 (D) mm
(Including front panel: 5-27/32 (W) X 1-11/16 (H) X 8-
7/32 (D) in).
Weight:
1.0 Kg (2.2 Lb)
Operation temperature:
+5°C to +45°C (41°F to 113°F)
Operation humidity:
5% to 85% (no condensation).
Storage temperature:
-20°C to +60°C (-40°F to 140°F)
Storage humidity:
5% to 90% (no condensation).
