ISHVW CONNECTOR Instruction Manual
Document No.
HDM-0012
3 / 29
Confidential C
1.Purpose
The Manual explains the handling of ISHVW CONNECTOR.
2.Applicable items
The Manual is applicable to the items listed below.
MALE TERMINAL
VT002-012
Name
Part No.
FEMALE TERMINAL
VT001-512
MALE CONNECTOR
FEMALE CONNECTOR
Fig.1 Product summary
