IAI TB-02 - Supported Models

Treatment in an Emergency
When any error occurs, alarms and messages on the display come from controllers or the touch panel
teaching. Depending on the alarm or message code, confirm Instruction Manual of each controller or the
touch panel teaching (DVD manual).
Applicable for Position Controller / ELECYLINDER
Error level
Error No.
(
HEX
)
Referent
Controllers warnin
g
000 ~ 7FF
Please refer to Instruction Manual provided with
each controller.
Controllers erro
r
080 ~ 0FF
Touch panel teachin
g
: messa
g
e 100 ~ 1FF
Please refer to Instruction Manual for the touch
panel teaching pendant TB-02 applicable for
position controller / ELECYLINDER.
Touch panel teaching: operation
cancel erro
r
200 ~ 2FF
Touch panel teachin
g
: cold start erro
r
300 ~ 3FF
Applicable for Program Controller (Except for RSEL)
Error level
Destination for
system error
assi
g
nmen
t
Error No.
(HEX)
Remarks
Secret level
Main application
par
t
800 ~ 88F
Special error level for maintenance
Main core par
t
890 ~ 8AF
PC 8B0 ~ 8DF
TP 8E0 ~ 8FF
Message level
Main application
par
t
200 ~ 24F, 900 ~ 93F
A00 ~ A6F
Status display, input error, etc.
Main core par
t
940 ~ 97
F
, A70 ~ A9F
PC
250 ~ 29F, 980 ~ 9AF
AA0 ~ ACF
PC
(
Update tool
)
2A0 ~ 2CF, 9B0 ~ 9BF
TP
2D0 ~ 2FF, 9C0 ~ 9FF
AD0 ~ AFF
Operation
cancel level
Main application
par
t
400 ~ 4CF, B00 ~ B9F
C00 ~ CCF
It is an error that hinders operation.
For miner errors below this level, error
cancelation gets attempted (on the application
part only) by the automatic reset feature at the
external active command (SIO / PIO).
Main core par
t
BA0 ~ BB
F
, CD0 ~ CDF
PC
4D0 ~ 4DF, BC0 ~ BDF
CE0 ~ CEF
PC
(
Update tool
)
4E0 ~ 4EF
TP
4F0 ~ 4FF, BE0 ~ BFF
CF0 ~ CFF
Cold start level
Main application
par
t
500 ~ 5CF, 600 ~ 6CF
D00 ~ D8
F
, E00 ~ E8F
It is necessary to reboot the controller power
supply (for main part only).
(Normal execution for CPU and OS)
Main core par
t
D90 ~ DA
F
, E90 ~ EBF
PC
6D0 ~ 6DF, DB0 ~ DCF
EC0 ~ EDF
PC
(
Update tool
)
6E0 ~ 6EF, DD0 ~ DDF
TP
6F0 ~ 6FF, DE0 ~ DFF
EE0 ~ EFF
System
shutdown level
Main application
par
t
FF0 ~ FBF
It is necessary to reboot the controller power
supply (for main part only).
(Execution Not Feasible for CPU and OS)
Main core par
t
FC0 ~ FCF
PC FD0 ~ FDF
TP FE0 ~ FEF
Applicable for Program Controller (RSEL)
Error level
Source of
error occurrence
Error No. Remarks
Secret level
Controlle
r
100 ~ 1AF
TP/PC 1B0 ~ 1FF
Message level
Controlle
r
200 ~ 2FF
TP/PC 300 ~ 3FF
Operation
cancel level
Controlle
r
400 ~ 4FF
TP/PC 500 ~ 5FF
Cold start level
Controlle
r
600 ~ 6FF
TP/PC 700 ~ 7FF
System
shutdown level
Controlle
r
F00 ~ FCF
TP/PC FD0 ~ FFF
PC: PC Software TP: Touch Panel Teaching Pendant
Refer to the instruction manual of the controller.
