14
System Block Diagram
INPUT
PRE BOOST GAIN BASS TREBLE LEVEL
BRIGHT
Center freq. level
OUTPUT
Pre boost
Distortion
5 band-parametric EQ
POST BOOST
Post boost
GATE
Noise gate
Dry signal detection
