ITEM NUMBER
REMARK Q'TY
DESCRIPTION
SW65 PARTS LIST
32S01888 B5 01 EL CAP 3300UF CAE338FMLRIN C404，405 2
32S00032 B5 01 EL CAP 1UF CAE105FMLRBC C105,C130 2
32S00267 B5 01 EL CAP 2.2UF CAE225FMLRBC C119,C123 2
32S00396 B5 01 EL CAP 3.3UF CAE335FMLRBC C107 1
32S01712 B5 01 EL CAP 10UF CAE106FMLRCC C103,118,121,301,303 5
32S00599 B5 01 Z. DIODE 1N4742A DZN12010H100 ZD403 1
32S00046 B5 01 Z. DIODE 1N4744A DZN15010H100 ZD401,402 2
32S00598 B5 01 DIODE 1N5402 DID1N5402RHD D401,402,403,404 4
32S00044 B5 01 DIODE 1N4148 DID1N4148DHB
D101,102,301,302,303,304D305,306,405,
406 10
32S00054 B5 01 LED DIA3 LEDC030HDANA LED301,401 2
32S01718 B5 01 LED WATER CLEAR LEDC050BLANA LED1 1
32S00047 B5 01 TRANSISTOR TST2SA1015GS Q107,108 2
32S01720 B5 01 TRANSISTOR TST2SA970XGS Q304 1
32S00048 B5 01 TRANSISTOR TST2SC1815GS Q101,102,104,105,106 5
32S01722 B5 01 TRANSISTOR TST2SC2240GS Q103,301,302,303,306 5
32S00602 B5 01 TRANSISTOR BD139 TSTBD139XXNM Q305 1
32S00604 B5 01 TRANSISTR TIP31C TSTTIP31CXNM Q307 1
32S00605 B5 01 TRANSISTR TIP32C TSTTIP32CXNM Q309 1
32S00609 B5 01 TRANSISTOR TST2SA1941OP Q310 1
32S00608 B5 01 TRANSISTOR TST2SC5198OP Q308 1
32S01908 B5 01 TRANSISTOR TST2N5401XYP Q312 1
32S01909 B5 01 TRANSISTOR TST2N5551XYP Q311 1
32S00800 B5 01 FET 2SK30AGR FET2SK30AXGW Q109 1
32S00053 B5 01 IC NJM4558DD IGCN4558DDAO IC1,IC2 2
32S01570 B5 01 IC CA3080E IGCCA3080EAO IC3 1
32S01733 B5 01 PCB TERMINAL TMN5XXXXMZ52 OUT1,T-1 2
32S01735 B5 01 AIR COIL 1.1UH IDT1R5N1A119 L1 1
32S01574 B5 01 PUSH SWITCH LOCK SWP2ASO1NL01 K1 1
32S00056 B5 01 DIA6.3 JACK MONO JKP6R3MOLA4N
JK101(INPUT),103(LINE
OUT),201(SEND),202(RETURN),203(SP
OUT) 5
32S00057 B5 01 DIA6.3 JACK STRO JKP6R3STDA6O JK104 PHONE JACK 1
32S01204 B5 01 RCA SOCKET 2P JKR1PCYVWGRD JK102 1
32S00629 B5 01 TESTING PIN 2.3 TMN2XXXXMZ05 T-3 1
32S01741 B5 01 VH CONNECTOR 3PL WAF2Y03SHH02 CN2 1
32S00562 B5 01 XH CONNECTOR 3PL WAF2Y03SHH04 CN1 1
32S01743 B5 01 CONNECTION WIRE HSNXH50CQ88J CN1-SCN1 3P 450mm GRAY 1
32S01744 B5 01 WIRE BK 80MM ECWA220BB080 LED1- -- LED- 1
32S01745 B5 01 WIRE BK 80MM ECWA222BB080 LED1+ -- LED+ 1
32S01746 B5 01 HEATSINK TUBE10M PPTHST020110 2
32S01926 B5 01 FUSE F4A/250V FUS520NFV040 F2，F3 2
32S00623 B5 01 FUSE HOLDER FUC520PNNNND F2，F3 4
32S01749 B5 01 VOLUME POT 1B100 VRRE1ECPK00A VR106 1
32S00265 B5 01 VOLUME POT B10K VRRE1ECPB10A VR101 1
32S00522 B5 01 VOLUME POT W20K VRRE1ECPW20C VR103,105 2
32S00390 B5 01 VOLUME POT B50K VRRE1ECPB50C VR102,104 2
32S01753 B5 01 SF VOLUME 470 SFR0505YA00A VR301 1
32S01754 B5 01 SF VOLUME 5K SFR0505YA05A VR302 1
32S01934 B5 01 250 CONNECT WIRE HSN25XX4402G OUT1-OUT2 440mm 1
32S01935 B5 01 250 CONNECT WIRE HSN25XX4400G T-1—T-2 440mm BLACK 1
32S01936 B5 01 HEATSINK HSK-54 HSKER4496054 60mm 1
32S01215 B5 01 HEATSINK CLAMP SPTUSHBA75-5 BA-75-5 1
32S00064 B5 01 TR INSLT PLATE PPTTWH203530 Q307,Q309 2
32S00063 B5 01 MICA SHEET TO220 SPTMGATO220X Q305,Q307,309 3
32S00626 B5 01 MICA SHEET SPTMGATO3PXX Q308,Q310 2
32S01941 B5 01 WIRE CLAMP PPTCBESUST01 2
32S01942 B5 01 SCREW BK M3 P0.5 MSRU30XR5068 L6 6
32S00066 B5 01 SCREW M3 P0.5L10 MSRR30XR510B Q305,307,309 3
32S00631 B5 01 SCREW M3 P0.5L12 MSRR30XR512B Q308,Q310 2
