ITEM NUMBER
REMARK Q'TY
DESCRIPTION
SW65 PARTS LIST
32S00068 B5 01 TOOTH WASHER D3 WSRO0632R5WS Q305,308,310 3
32S00012 B5 01 CF RESISTOR 7.5K RCF075203JUH R107 1
32S01947 B5 01 CHASSIS SW65 STCSW65XXXZB 1
32S01948 B5 01 TRANSFORMER 100V TRMSW65XXXX0 1
32S01949 B5 01 TRANSFORMER 120V TRMSW65XXXXL 1
32S01950 B5 01 TRANSFORMER 230V TRMSW65XXXX3 1
32S01951 B5 01 TRANSFORMER 240V TRMSW65XXXX4 1
32S01595 B5 01 POWER SWITCH SWRYBBL6NQ1F 4PIN 1
32S00074 B5 01 AC SOCKET ACS3QKPUM102 1
32S01774 B5 01 LED HOLDER PPTLDA647178 DIA5 1
32S01747 B5 01 FUSE F3.15A/250V FUS520NFVO31 F1 100V/120V 2
32S01956 B5 01 FUSE T1.6A/250V FUS520NSVO16 F1 230V/240V 2
32S00073 B5 01 CERAMIC CAP0.01U CCR103A40ZYS 1
32S00076 B5 01 KNOB RKN-20BK RKNBKWH18R20 6
32S01958 B5 01 PUSH SWITCH PKNS090711BE BLACK 1
32S00459 B5 01 SCREW M3 P0.5 L6 MSRU30XR506B L6 6
32S01960 B5 01 SCREW BK M4 P0.7 MSRR40XR710B L10 4
32S00080 B5 01 SCREW NI M4 P0.7 MSRU40XR712N L12 1
32S01604 B5 01 TAP SCREW 3X8 TSRR30X08WDN 1
32S00084 B5 01 TOOTH WASHER D4 WSRO0844R5WS 2
32S00086 B5 01 WASHER10DX4.2DX1 WSRF104210WS 1
32S00078 B5 01 SOLDERING PLATE SPTSDPXXTP-1 TP-1 1
32S00083 B5 01 NUT M4 P0.7 NUTM40XPR7HS 2
32S00087 B5 01 CABLE TIE PPTCBTN08025 80mm 5
32S01792 B5 01 TRANS COVER SPTTFESW35-3 1
32S01250 B5 01 PCB SPACER SPTBSS5XM315 L15 1
32S01970 B5 01 LABEL GND LABWHBKAG001 1
32S01971 B5 01 187 CONNECT WIRE HSN17172600A 18AWG 260mm BLACK 1
32S01972 B5 01 187 CONNECT WIRE HSN17172602A 18AWG 260mm 1
32S01786 B5 01 187 CONNECT WIRE HSN17XXCQGDA 18AWG 180mm YELLOW 1
32S01974 B5 01 CLAMP SPTSTCMCRBS4 MICROBASS-4 2
32S01975 B5 01 CABINET SW65 BOXSW65XX661 1
32S01976 B5 01 SPEAKER SW65 SPKPJ1204X01 PJ1204 1
32S01977 B5 01 TWEETER SW65 SPKKP308-M01 1
32S01978 B5 01 SPEAKER LABEL LABWHBKAE008 PJ-PGG85 1
32S01797 B5 01 6.3 CONNECT WIRE HSN6M20CQ70G 18AWG MONO 650mm 1
32S00098 B5 01 CORNER PCN-7 PCNPEXBK2807 8
32S00867 B5 01 RUBBER FOOT PPTRFT143002 RUB-2 6
32S00473 B5 01 STRAP HANDLE HDP215P25802 HDP-2 1
32S00474 B5 01 HANDLE CLAMP HDCSTEKBLK01 HDC-1 2
32S01626 B5 01 LOGO PLATE PLGLGBSIBN0D IBANEZ BLACK 1
32S01627 B5 01 LOGO PLATE SW PLGBKSVIBZ01 1
32S01615 B5 01 SP FIXING CLAMP SPTSPHSW35-5 6
32S00868 B5 01 POWER CODE JP PWCD--DBVTF3A 1
32S00869 B5 01 POWER CODE UL PWCA--DBSVT3A 120V 60Hz 1
32S00104 B5 01 POWER CODE EU PWCE-DBH5V3A 1
32S01060 B5 01 POWER CODE UK PWCF--DBH5V3A 1
32S01624 B5 01 POWER CODE AUS PWCI--DBLTS3A 240V 50Hz 1
32S01625 B5 01 POWER CODE ARG PWCJ--DBH5V3A 240V 50Hz 1
32S01636 B5 01 CABLE TIE PPTCBC622395 FOR SP CABLE 1
32S01994 B5 01 205 CONNECT WIRE HSN20202302G 18AWG 230mm 1
32S01995 B5 01 205 CONNECT WIRE HSN20202300G 18AWG 230mm BLACK 1
32S00677 B5 01 SCREW BK M4 P0.7 MSRH40XR732B L32 2
32S00484 B5 01 SCREW BK M4 P0.7 MSRH40XR728B L28 4
32S01814 B5 01 SCREW BK M4 P0.7 MSRR40XR720B L20 6
32S00111 B5 01 TAPPING SCREW TSRS25X08WDB BK2.5×8 2
32S01816 B5 01 TAP SCREW 3.5X10 TSRU35X10WDB BLACK 16
32S01633 B5 01 TAP SCREW 4X12 TSRU40X12WDB BLACK 5
32S00888 B5 01 TAP SCREW 4X20 TSRU40X20WDB BLACK 6
