TA225 PARTS LIST
3200956 AA 01 ELECTRO CAP 2.2UF 50V(NP) C5,89,96 3
3200323 AA 01 ELECTRO CAP 3.3UF 50V(NP) C15 1
3201131 AA 01 ELECTRO CAP 4.7UF 50V(NP) C3,10,13 3
3200958 AA 01 ELECTRO CAP 10UF 16V(NP)
C14,17,23,28,29,31,33,34,38,81,82,91
,98,301,302 15
3200324 AA 01 ELECTRO CAP 22UF 25V(NP) C101,118 2
3201134 AA 01 ELECTRO CAP 33UF 25V(NP) C85,92 2
3201135 AA 01 ELECTRO CAP 4.7UF 100V(NP) C145,146 2
3200139 AA 01 ELECTRO CAP 1UF 50V C49,50 2
3200140 AA 01 ELECTRO CAP 4.7UF 50V C107,108,125,126 4
3200141 AA 01 ELECTRO CAP 10UF 50V C42,51 2
3200787 AA 01 ELECTRO CAP 100UF 25V C138,139,140,141 4
3200471 AA 01 ELECTRO CAP 100UF 50V C110,113,115,130 4
3200966 AA 01 ELECTRO CAP 3300UF 50V (SHL) C134,135 2
3200328 AA 01 CONNECTOR 5267-02P CW3,4,CH19,22 4
3200968 AA 01 CONNECTOR 5267-03P CH15,23 2
3200329 AA 01 CONNECTOR CW1143-03 CW2 1
3200971 AA 01 HEATING TUBE DIA10 TUBE 20mm 1
3200334 AA 01 CLOSE & CONNECT DIA4.5 UL AC PRIMARY CONNECTION 1
3209022 AA 01 SPEAKER(WOOFER) PSR-005B SPK1,2 2
3200795 AA 01 SPEAKER(TWEETER) BP013G1 SPK3,4 2
3201149 AA 01 PCB ASSY TA225 TA-225 MAIN BOARD 1
3200975 AA 01 AC CORD DETACHED 100V(JAPAN) 1
3200976 AA 01 AC CORD DETACHED 120V(USA/CANADA) 1
3200977 AA 01 AC CORD DETACHED 230V(EUROPEAN) 1
3200978 AA 01 AC CORD DETACHED 240V(AUSTRALIA ) 1
3201154 AA 01 MAIN CHASSIS EGI 1.2T 1
3201155 AA 01 WOODEN CABINET PB20T 1
3201156 AA 01 FRONT PANEL PVC 0.5T 1
3201157 AA 01 REAR PANEL PVC 0.5T 1
3200813 AA 01 CORNER(FRONT) METAL GOLD 4
3200814 AA 01 CORNER(REAR) METAL GOLD 4
3200085 AA 01 FOOT ASS'Y 4
3201161 AA 01 HANDLE ASS'Y GOLD, 220mm 1
3200224 AA 01 CONTROL KNOB LIGHT BROWN 13
3200988 AA 01 HEAT SINK AL 1
3200989 AA 01 HEAT SINK BRKT EGI 1.0T 2
3200226 AA 01 LOGO (SPAGHETTI) 1
3200091 AA 01 PUSH KNOB 1
3201167 AA 01 INSTRUCTION MANUAL TA225 1
3200993 AA 01 BIAS TR BRKT 1.0T 2
3200994 AA 01 CORD BUSHING TB225 3
3200093 AA 01 STAR WASHER DIA4 2
3200094 AA 01 GND LABEL 2
3201172 AA 01 SPEAKER LABEL PJ30B 2
3201173 AA 01 CARTON BOX DW-2 TA225 1
3200999 AA 01 SNOW PAD TB225 8
3200359 AA 01 FALT 280X17X1T 6
3201002 AA 01 HEAT SINK(B) 14.8X10.6X27L 2
3201003 AA 01 SCREW1 DIA4X10 TRU, BLACK GND:2 2
3201004 AA 01 SCREW2 DIA3X6 BH, BLACK, TTS HEAT SINK+CHASSIS:4,HEAT SINK BRKT:4 8
3200362 AA 01 SCREW3 M3X8,BH,ZN BIAS TR:2,PCB:2 4
3201180 AA 01 SCREW4 M3X12, SW, TR:6 4
3201181 AA 01 SCREW5 TAPPING WW DIA3X8L PCB+HEAT SINK BRKT:2 2
3201008 AA 01 SCREW6 M4X10L POWER TRANS:4 4
3201009 AA 01 SCREW7 TAPPING 1 DIA2.6X10,FH,BK VENT COVER:4 6
3201184 AA 01 SCREW8 TAPPING 1 DIA3.5X10, GOLD CORNER:20 20
3201185 AA 01 SCREW9 TAPPING 1 DAI3.5X30,BH,BK BAFFLE:6,BACK COVER:8 14
