Qscan User’s Guide Version 1.4

Page 30

Wiegand Format # 1 (barcode) Site Override

X018 ssss

ssss site override hexadecimal

This command sets the site override value for wiegand format # 1 for

barcode data.

This command species the site override value for wiegand format # 1 for use

with barcode data. If the site override option is on, then the site eld data is

replaced with the (“ssss”) value. (“ssss”) is programmed as 4 hexadecimal

characters, representing 16 bits. If the site eld is larger than 16 bits, the

(“ssss”) data will be right justied in a zero lled eld. If the site eld is smaller

than 16 bits, then the lowest bits in the override value are used up to the size

of the site eld.

PROGRAMMING BARCODE -> WIEGAND OUT

Wiegand Format # 2 (barcode) Site Override

X022 ssss

ssss site override hexadecimal

This command sets the site override value for wiegand format # 2 for

barcode data.
