Qscan User’s Guide Version 1.4
Page 37
PROGRAMMING
PROX ICLASS
Proximity and iClass General Settings
X047 c m b p s
c card style 1=wiegand 2=aba
m masking 0=off 1=on
b good read beep 0=off 1=on
p parity check (26 & 28) 0=off 1=on
s passthru 0=off 1=on
This command sets the general settings for proximity and iClass input.
If passthru (“s”) is turned on, and the output mode is set to wiegand,
then no interpretation of the prox or iClass data is done. The card data is
transmitted exactly as it is on the card.
Proximity and iClass Input, Format # 1, Part 1*
X048 bbb sss sl b bss bl x
bbb # card bits max=250
sss site start bit 000=no site
sl # bits for site code 00=none
b site is lsb 0=off 1=site is lsb
bss id start bit 000=no id
bl # bits for id 00=none
x id is lsb 0=off 1=id is lsb
This command is the rst part of a 2 part command, for setting up an
input proximity or iClass format.
* added to rmware 5/22/13
