Qscan User’s Guide Version 1.4
Page 46
Wiegand Output Format (for prox/Iclass data Format # 2)*
X063 ss sl is il us ul
X064 sb ib ub a b c lpp rpp
X065 1 2 3 oooo ss
All parameters are the same as the prior command.
* added to rmware 5/22/13
PROGRAMMING
Wiegand Output Format (for prox/Iclass data Format # 3)*
X066 ss sl is il us ul
X067 sb ib ub a b c lpp rpp
X068 1 2 3 oooo ss
All parameters are the same as the prior command.
* added to rmware 5/22/13
PROX/ICLASS -> WIEGAND OUT
Wiegand Output Site Override Control (for prox/iClass formats)*
X069 a b c
a site override, format 1 0=off 1=on
b site override, format 2 0=off 1=on
c site override, format 3 0=off 1=0n
If any site overrides are specied for any of the three formats, they must
be activated using this command, otherwise the overrides are not used.
* added to rmware 5/22/13
