3. Pull the 2000-sheet finisher away from printer to be able to reach the lower paper
access cover. (See Figure 3 on page 5 to locate covers.)
c9pu164
4. Open the upper paper access cover.
5. Remove jammed paper as shown below:
c9pu166
6. If paper is jammed in the face-up tray, lift the paper guide (1), and remove the
paper (2). Lower the paper guide back into place.
c9pu169
1
1
2
134 User's Guide
