c9pu050
2
3
1
9. Place the controller board back into the printer.
FLASH
DRAM
2
1
c9pu320
10. At the back of the printer, tighten the screws that fasten the controller board.
11. Connect the cables to the controller board.
12. Connect the power cord to the back of the printer.
13. Connect the other end of the power cord to a grounded AC outlet.
14. Switch the printer power on.
15. Attach communication cable between the 2000-sheet input drawer and the options
controller card.
16. After the printer warms up, the READY message displays on the operator panel.
164 User's Guide
