IBM 24 - Page 273

c9pu231
=
=
2
2
1
1
8. Grasp the handles of the new fuser assembly and slide it completely into its mount.
c9pu232
9. Turn the two blue lock levers (1) of the fuser assembly in the direction of the
arrows shown below.
Appendix D. Installing the Usage Kit 249
