IBM 24

c9pu271
2
1
7. Raise the lever (1). Insert your finger into the hub and press the lock tab (2) of the
bottom pick-up roller (3) and remove the roller from the printer.
c9pu272
2
3
1
8. Slide the new pick-up roller (1) onto the top shaft (2).
262 User's Guide
