IBM 3000VA LCD 3U Rack Uninterruptible Power Supply for IBM System x 6
Table 3. Specifications (Part 2 of 2)
Specification IBM 3000VA LCD 3U Rack
UPS (100V/120V)
IBM 3000VA LCD 3U Rack
UPS (200V/208V)
IBM 3000VA LCD 3U
Rack UPS (230V)
Communications and management
USB port Yes Yes
RS-232 serial port Yes Yes
Ethernet port Optional using Network Management Card, 46M4110
Environmental Monitoring
Probe
Optional Environmental Monitoring Probe, 46M4113
Surge Protection and Filtering
Surge energy rating 1200 Joules 2400 Joules 2400 Joules
Filtering ANSI/IEEE C62.41; 1991 CATEGORYB3 (SURGE)
Battery run times and recharge times
The following tables list the expected period that the UPS will operate solely on batteries. Table 4 is for
the 100V/120V model, Table 5 is for the 200/208V model, and Table 6 is for the 230V model.
Table 4. IBM 3000VA UPS (100V/120V) runtime chart
Load Run time on batteries
Percent
Load
VA Watts Run time with standard internal
battery only
Run time with internal battery plus
External Battery Module (EBM)
25% 720 678 42 minutes 156 minutes
50% 1440 1350 16 minutes 62 minutes
75% 2160 2060 10 minutes 42 minutes
100% 2880 2700 7 minutes 27 minutes
Table 5. IBM 3000VA UPS (200V/208V) runtime chart
Load Run time on batteries
Percent Load VA Watts Run time with standard internal
battery only
Run time with internal battery plus
External Battery Module (EBM)
25% 710 660 41 minutes 153 minutes
50% 1420 1340 17 minutes 68 minutes
75% 2140 2040 10 minutes 43 minutes
100% 2810 2660 6 minutes 29 minutes
