IBM 3453 Series User Manual

© Copyright IBM Corporation 2019, 2020. Customer Install Guide, 2U Chassis 16
Cloud Pak for Data System 2U chassis
hardware specifications
Hardware specifications below provide information for the Cloud Pak for Data System
2U chassis, including dimensions, electrical power and cooling. .
All component installation documents are available on the Safety and Regulatory CD
that comes with your Cloud Pak for Data System components.
3453-XXX, Cloud Pak for Data System (2U server chassis) [see Notes 1, 2]
Table 1
Width Depth Height
EIA
units
Weight
Amperage
(Max)
Power
(Max)
Cooling
(Max)
488 mm
(19.3 in)
891.5 mm
(35.1 in)
87 mm
(3.5 in)
2
55 kg
(121.2 lb)
10 amps
2000
watts
6800
BTU/Hr
Notes:
[1] The power supplies automatically accept any voltage within the 200-240 V AC,
50/60 Hz rated-voltage range. If dual power supplies are installed and operating, the
power supplies draw approximately equal current from the utility (electrical supply) and
provide approximately equal current to the load.
[2] Power draw and heat load vary greatly by configuration and work load. When you
plan for an electrical system, it is important to use the maximum values but actual power
and cooling will be less.
