B B
S T
8 8
TAPE READ
MAP
PAGE 13
OF
45
117
ERROR
970--STATUS ERROR.
Unexpected beginning
or
end
of
tape status
active.
-Observe which reel
of
the tape cartridge has
the most tape on it.
Does
the
right
reel
have
more
tape
on
it
than
the
left
reel?
Y N
118
-Press C
to
call the tape repositioning
option.
-Next press B to call the reverse tape
repositioning routine.
Go
to
Page 1.
Step
001.
Entry
Point
A.
119
-Press C to call the tape repositioning option.
-Next press F
to
call the forward tape
repositioning routine.
Go
to
Page
1.
Step
001.
Entry
Point
A.
120
ERROR
966--STATUS ERROR.
BOT Status cannot
be
cleared (status bit 7 was
0,
should have been
1).
-If
you are not sure
of
the answer to the next
question, answer
it
N.
Is
the
tape
moving
too
slow?
Y N
1 1
3 3
C C
N P
c C
N P
1 1
3 3
121
MAP
0300-13
-Run the tape speed test by pressing
EXECUTE on the keyboard.
Is
ERROR 973
now
displayed
on
the
display?
Y N
122
Defective
F2
(base
I/O)
card.
123
Service check/adjust the
motor
pulley (refer
to
226).
Service check/adjust the cartridge stop blocks
(refer to 224).
Inspect the jackshaft housing and the spindle
for
binds (refer to 202).
Service check/adjust the magnet gaps (refer
to 222).
Defective tape motor assembly (refer
to
202).
Defective diagnostic
~ape
cartridge.
Defective spindle-select arm assembly (refer
to
202).
Defective jackshaft housing assembly (refer
to
202).
124
Tape might be moving too slowly.
Service check/adjust the
motor
pulley (refer
to
226).
Service check/adjust the cartridge stop blocks
(refer
to
224).
Inspect the jackshaft housing and the spinole
for
binds (refer
to
202).
Servic;e check/adjust the magnet gaps (refer
to
222).
Defective tape motor assembly (refer
to
202).
Defective diagnostic tape cartridge.
Defective spindle-select arm assembly (refer
to
202).
Defective jackshaft housinQ assembly (refer
to
202).
28SEP76
PN
1608386
EC
829670
PEC
828851
MAP
030(}'13
To Next Page
