Chapter 4. Configuring the PeerMaster Adapter
Some PC Server 520 models come with an IBM Ethernet Quad-BT
PeerMaster Server Adapter installed as a standard feature. This
chapter contains instructions for configuring, cabling, and testing the
PeerMaster adapter. You must configure, cable, and test the
PeerMaster adapter before you install your network operating
system and the PeerMaster LAN software.
This chapter contains:
Choosing a Mode of Operation
................... 138
Traditional Adapter Mode .................... 138
VNET Switch Mode ........................ 139
Configuration Examples . . . . . . . . . . . . . . . . . . . . . . 140
Using the PeerMaster Setup Utility Program ........... 147
Displaying the PeerMaster Adapter ............... 148
Guidelines for Assigning Slot Numbers ............ 149
Running PeerMaster Diagnostic Programs ........... 151
Displaying PeerMaster PCI Configuration Registers ..... 153
Attaching Network Cables to Your Adapter ........... 155
