Chapter 5. Installing Options
This chapter provides instructions to help you add options to your
server. Some option-removal instructions are provided, in case you
need to remove one option to install another. If you have several
internal options to install, these instructions enable you to add them
all at one time. See “Installation Sequence” on page 184 for the
required installation sequence for installing a combination of
industry-standard architecture (ISA), extended industry-standard
architecture (EISA), and peripheral component interconnect (PCI)
adapters in your server.
This chapter contains:
Before You Begin
........................... 159
Moving the Server ........................... 160
Electrical Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Handling Static-Sensitive Devices ................. 162
Preparing to Install Options ..................... 163
Installing Memory-Module Kits ................... 169
Removing Memory-Module Kits .................. 175
Installing Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Installation Sequence . . . . . . . . . . . . . . . . . . . . . . . 184
Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . 185
Removing Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . 192
Installing Internal Drives ....................... 197
Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
SCSI Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Preinstallation Steps (All Bays) ................. 204
Installing a Drive in Bay B .................... 207
Installing a Drive in Bank C ................... 216
Installing a Drive in Bank D ................... 221
Installing a Drive in Bank E ................... 233
Removing Internal Drives ...................... 241
Removing a Drive from Bay B .................. 242
Removing a Drive from Bank C, D, or E ............ 245
Changing Jumper Settings ...................... 249
Installing a Microprocessor ..................... 255
Security Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Security-Cover Option . . . . . . . . . . . . . . . . . . . . . . . 263
Installing a U-Bolt ......................... 264
Completing the Installation ..................... 266
