Installing Internal Drives
Note: All internal drives in this server are mounted vertically.
1. Choose the bay in which you want to install the drive.
2. Touch the static-protective bag containing the drive to any
unpainted metal surface on the server; then, remove the drive
from the bag.
Static
Devices
3. Check the instructions that come with the drive to see if you
need to set any switches or jumpers on the drive, or if you need
to attach a tray to the drive.
Notes:
Automatic SCSI ID setting applies only to hot-swap
hard disk drives. Therefore, if you install a
non-hot-swap SCSI drive (in bay B only), you must
set a SCSI ID for that drive.
Remove the terminators from the drives that you plan
to install in bay B. The cable that connects to bay B
already has a terminator.
Chapter 5. Installing Options 205
