Input/Output Connectors
Input/Output Connectors
Power Connector
Monitor Connector
Serial Connectors
Parallel Connector
Expansion Slots
SCSI Connector
(Non-Disk-Array Models)
SCSI Connector
(Disk-Array Models)
SCSI Connector
Knockout
Keyboard Connector
Mouse Connector
Notes:
1. Some models come with a preinstalled ServeRAID
adapter in a PCI expansion slot.
2. Some models come with a preinstalled PeerMaster
adapter in a PCI expansion slot.
3. For pin assignments and other details about these
connectors, see the User's Reference.
