Expansion Bays
Your server comes with one 3.5-inch, 1.44 MB diskette drive, a SCSI
CD-ROM drive, and a removable CD-ROM storage compartment.
(1 MB equals approximately 1000000 bytes.) The number of
preinstalled hard disk drives in your server varies according to the
model that you purchased.
CD-ROM Drive
Diskette Drive
Hard
Disk Drives
Open Bays
Open Bays
CD-ROM Drive: All models come with a SCSI-2 CD-ROM
drive.
Diskette Drive: The 3.5-inch, 1.44 MB diskette drive uses 1 MB
and 2 MB diskettes.
Open Bays: Your server has a special design that gives you the
flexibility to use up to 18 hot-swap, 3.5-inch hard disk drives.
There is additional open space in the top left bay for two more
diskette drives or an additional SCSI drive. For installation
instructions and information on the types of drives that you can
install in each bay, see Chapter 5, “Installing Options” on
page 153.
8 PC Server 520 User's Handbook for PCI/EISA
