8. Reinstall the fan tray and each power supply, making sure the screws are
secured, refer to Figure 1-7.
Note: If you need to reinstall adapters, refer to Appendix B, “MAE
Adapters Plugging Rules” on page B-1.
Figure 1-7. Installing Fan Tray and Power Supply
Do you have to install a second ac outlet distribution box ?
Yes, go to Step 9.
No, go to Step 17 on page 1-10.
9. Identify the two locations for captive nuts .A/.
Rear View
A
Figure 1-8. Locating the Captive Nuts
1-8 3746-9X0: MAE Installation and Maintenance
