Feature code 7884 and 0229
Table 38. Feature code 7884
IBM rack Rack, specify code PDU support Power cords
0551
1
0553
1
7014
4
0555
7884, 0229 0 to 4
2
7884, PDU
3
1
0551 is an empty 1.8 meter rack with 36 EIA units of total space. 0553 is a 2.0 meter rack with 42 EIA units of total
space.
2
0551, 0553, and 0555 feature codes 5160, 5161, 5163, and 7188. 7014 feature codes 7176, 7177, 7178, and 7188.
3
If units plug into a power distribution unit (PDU), power jumper cord feature code 6458, 6459, 6095, or 9911 is
required. If redundant power supply (feature code 5158) is ordered, a second power jumper cord feature code is
required.
4
7014-T00 is a 1.8 meter rack with 36 EIA units of total space. 7014-T42 is a 2.0 meter rack with 42 EIA units of total
space. The rack includes one PDU, feature code 9188, 9176, 9177, or 9178.
Figure 5. Feature code 7884
22 Site and hardware planning
