IBM 9008-22L Site And Hardware Planning

Table 51. Environment requirements (continued)
Environment Operating Nonoperating
Maximum altitude 3048 m (10 000 ft) 3048 m (10 000 ft)
Table 52. Noise emissions
Properties Operating Idle
L
WAd
(Category 2E, General business) 6.6 bels 6.3 bels
<L
pA
>
m
48 dB 46 dB
For a description of noise emission values, see Acoustics.
Table 53. Service clearances
Front Back Sides Top
762 mm (30 in. ) 762 mm (30 in. ) 762 mm (30 in. ) 762 mm (30 in. )
Side and top clearances are optional when operating.
Notes:
1. The 1.8 meter rack has six EIA units of space remaining. This space will be filled with a three-EIA
filler panel and three of the one-EIA filler panels.
2. Only the 4.3 m (14 ft) power cord features are offered for racked 9406-270 systems. There are a total of
four power cords that are routed through cable management arms. Also, there is a cable management
device that might be used to restrict the length of the power cord exiting the bottom of the rack. See
model 9406-270 Cable Poster Addendum included with the 0551 model 9406-270 rack.
3. The rack does not have power distribution. Each model 9406-270 and 7104 requires a power cord of
sufficient length to reach the receptacle. The power cord feature codes for model 9406-270s must be
used to determine the appropriate receptacles.
Model 0554 and 7014-S11 rack
Hardware specifications provide detailed information for your rack, including dimensions, electrical,
power, temperature, environment, and service clearances.
Table 54. Dimensions
Dimension Properties
Height 611 mm (24 in.)
Capacity 11 usable EIA units
Height with PDP - DC only Not applicable
Width without side panels Not applicable
Width with side panels 518 mm (20.4 in.)
Depth without doors 820 mm (32.3 in.)
Depth with front door 873 mm (34.4 in.)
Depth with sculptured style front door Not applicable
Weight Base rack (empty) 36 kg (80 lb)
Weight Full rack
1
218 kg (481 lb)
Table 55. Electrical
Electrical characteristics Properties
DC rack voltage (nominal) Not applicable
30 Site and hardware planning
