Table 57. Dimensions (continued)
Dimensions Properties
Width without side panels 590 mm (23.2 in.)
Width with side panels 610 mm (24 in)
Depth with back door only 996 mm (39.2 in.)
Depth with back door and front door 1000 mm (39.4 in.)
Depth with sculptured style front door Not applicable
Base rack (empty) 98 kg (217 lb)
Full rack
1
665 kg (1467 lb)
Table 58. Electrical
Electrical characteristics Properties
DC rack voltage (nominal) Not applicable
Power source loading maximum in kVa Not applicable
Voltage range (V dc) Not applicable
AC rack See your server or hardware specifications for specific
requirements
Power source loading maximum in kVa (per PDU) See your server or hardware specifications for specific
requirements
Voltage range (V ac) See your server or hardware specifications for specific
requirements
Frequency (Hz) 50 or 60
The 7188 power distribution unit used with this rack is mounted horizontally and requires one EIA unit of space.
Table 59. Service clearance
Front Back Sides
915 mm (36 in.) 760 mm (30 in.) 915 mm (36 in.)
See your server or hardware specifications for specific temperature and humidity requirements.
Rack noise levels are a function of the number and type of drawers installed. See your server or
hardware specifications for specific requirements.
Rack airflow requirements are a function of the number and type of drawers installed. Refer to the
individual drawer specifications.
Notes:
1. Configuration dependent, base rack weight plus the weight of the drawers mounted in the rack. The
rack can support up to a maximum weight of 22.7 kg (50 lb) per EIA unit.
2. Recommended minimum vertical service clearance from floor is 2439 mm (8 ft).
Site and hardware planning 33
