Table 40. Electrical
1
Electrical characteristics Properties
Power source loading maximum in kVA For more information about rack power distribution
units and power cord options, see Power distribution
unit and power cord options for 7014 racks.
1
The total rack power can be derived from the sum of the power that is used by the drawers in the rack.
See your individual server or hardware specications for temperature and humidity requirements.
Rack noise levels depend on the number and type of drawers installed. See your server or hardware
specications for specic requirements.
Note: All rack installations require careful site and facilities planning that is designed to both address the
cumulative drawer heat output and provide the airflow volume rates necessary to comply with drawer
temperature requirements. All rack installations require careful site and facilities planning that is
designed to address both the cumulative drawer heat output and provide the airflow volume rates
necessary to comply with drawer temperature requirements. Rack airflow requirements depend on the
number and type of drawers installed.
Note: Acoustic doors are available for IBM racks. Feature code 6248 is available for 7014-T00 racks.
Feature code 6249 is available for 7014-T42 racks. The overall sound reduction is approximately 6 dB.
The doors add approximately 381 mm (15 in.) to the depth of the racks.
Service clearances
Table 41. Service clearances for 7014-T00 and 7014-T42 racks
Front Rear Sides
915 mm (36 in.) 915 mm (36 in.) 915 mm (36 in.)
Note: Recommended minimum vertical service clearance from the floor is 2439 mm (8 ft).
Figure 3 on page 32 provides the caster and leveler locations for 7014-T00 and 7014-T42 racks.
Site and hardware planning
31
