IBM 9009-22A

Figure 36. Removing the BPM
j) Place the BPM on an appropriate ESD surface.
k) Carefully remove the BPM cable from the cutout (A) in the opening below the BPM tray and
through the cutout (B) in the bulkhead. See the following gure.
38
Power Systems: System backplane
