8. Look for the PCI adapter location codes in the Location column.
9. Write down the Type-Model number for each PCI adapter location.
Some adapters can show multiple, virtual ports. It is not necessary to write down these virtual
locations.
10. Write down any PCI adapter locations that are listed in the Description column as an Empty
Position.
The Type-Model number is blank for empty positions.
11. Press F12 to return to the previous window.
12. Do you have an expansion unit attached?
• No: Go to “Adapter placement rules and slot priorities for the 9040-MR9” on page 1.
• Yes: Do the following tasks:
a. Type 9 for the System Expansion Unit eld and press Enter.
b. Repeat steps 7-11 for each expansion unit.
c. Select an available slot in the expansion unit.
16Power Systems: Adapter placement for the 9040-MR9
