Adapter placement for the 9040-MR9

Find information about the placement rules and slot priorities of adapters.

The following features are electromagnetic compatibility (EMC) Class B features. See the Class B Notices

in the Hardware Notices section.

Table 1. Electromagnetic compatibility (EMC) Class B features

Feature Description

EN0W PCIe2 2-port 10 GbE BaseT RJ45 Adapter

Adapter placement rules and slot priorities for the 9040-MR9

Find information about the placement rules and slot priorities for the adapters that are supported for the

9040-MR9 system.

Slot descriptions for the 9040-MR9

The 9040-MR9 systems provide PCIe3 and PCIe4 slots. The 9040-MR9 systems offer two or four

POWER9 processor modules. The PCIe slots are enabled to support the PCIe3 cable adapter (FC EJ08 or

FC EJ20) that is used to attach the EMX0 PCIe Gen3 I/O expansion drawer.

Table 2 on page 1 provides information about the PCIe switches in the 9040-MR9 systems.

Two PCIe3 switches (24-port PLX PEX 8725) in the system backplane provide PCIe3 buses from the

system processor modules that provide connectivity to the following features:

• PCIe slots

• PCIe local area network (LAN) controller

• PCIe3 internal SAS controller

Table 2. PCIe3 switches (24-port PLX PEX 8725) in the system

Features provided Switch 1 and Switch 2

Lanes and ports 24-lane, 10-ports, PCIe3

With integrated 8.0 gigatransfers per second (GT/s)

Serializer/Deserializer (SerDes) speed negotiation for

each port

Lane and polarity reversal Supported

All ports support concurrent maintenance through I2C

bus

Yes

End-to-end cyclic redundancy check (CRC) and poison

bit error checking

Supported

Data path parity Supported

Memory error correction Supported

Advanced error reporting Supported

Designate any port as the upstream port Yes

19x19 mm, 324-pin FCBGA package Yes

Power consumption Typical power: 5.4 watts
