Figure 93. Reconnecting the drive backplane power cable

m) Remove excess slack by pulling the BPM cable in the direction shown. See the following gure.

Removing and replacing the system backplane in the 5105-22E, 9008-22L, 9009-22A, 9009-22G, 9223-22H,

or 9223-22S 93
