Top System Board (Top View)
▌1▐ Keyboard Connectors
▌2▐ Inverter Card Connector
▌3▐ Microphone Connector
▌4▐ Speaker Connector
▌5▐ Battery Pack Connector
▌6▐ Lid Close Sensor
▌7▐ Parallel/Diskette Drive Connector
▌8▐ TrackPoint III Connector
3
6
28
5
1
7
4
184 IBM Mobile Systems HMM
