Page #61 background imageLoading...
Page #61 background image
1030 Backup Battery
1040 IC DRAM Card
1050 Standby Battery
 Battery Pack (1020)
Step 2: Standby Battery
Step 3: IC DRAM Card
Step 4: Backup Battery
Note
The IC DRAM card is sensitive to physical shock.
Incorrect handling of the card can damage it.
Note: When removing the backup battery or standby
battery, use the connector extractor (P/N
39G9977).
11
22
3
3
4
4
ThinkPad 340x (IBM 2610) 51
