2.
Slide
the
system
drawer
forward.
so
that
you
can
access
the
frame.
Attach
two
nut
clips
(C)
to
the
rack
rail
in
the
location
where
you
will
be
attaching
the
outer
plate
to
the
to
the
rail,
as
shown
in
Figure
18.
Figure
17. Attaching
the
inner
plate
to
the
system
chassis
Figure
18. Attaching
the
nut
clips
to
the
rack
rail
Installing
the
IBM
Power
System
E850
(8408-E8E)
17
32
34
