FlashSystem 900 Product Guide 7
Table 1. Specifications (part 2 of 2)
Specification
Description
Cooling Four hot-swappable fan modules.
Power supply 1300 watts, high-power version to run at maximum performance for
longer durations during power supply servicing. Two redundant
hot-swap 200 - 240V AC auto-sensing power supplies.
Input power 1300 watts maximum, 625 watts RAID5 typical operation, per 2U
Heat dissipation Approximately 2133 BTU (assuming 625W). For maximum
configurations, it could go as high as 3753 BTU (maximum
configuration using RAID 5).
Hot-swap parts All active components.
Security features AES-XTS 256 bit data-at-rest encryption with local key management.
Two new functions have been added to the encryption feature and can
be accessed by using the FlashSystem 900 GUI:
Hot Encryption Activation - Adding an encryption license to a
o
previously initialized system
Encryption Re-key - Changing the encryption key on a previously
o
initialized system
Platforms supported For specific information, see the IBM System Storage Interoperation
Center (SSIC) at
http://www.ibm.com/systems/support/storage/ssic/interoperability.wss
Warranty Set of Machine Types in AAS, 24 X 7 Service level Agreement, 4 hour
response time:
9840-AE2 - One year.
o
9843-AE2 - Three years.
o
Service and support Optional warranty service upgrades and post-warranty services are
available on site with 24x7 2-6 hour response, 24x7, or 9x5 same day,
or 9x5 next business day response,
Physical Specifications
Dimensions Width: 445 mm (17.5 in.) (19-inch Rack Standard)
Depth: 761 mm (29.96 in.)
Height: 86.2 mm (3.39 in.)
Weight
34 Kg ( 75 lb ) for fully configured machine ( 12 IBM MicroLatency
modules )
