Appendix A. Connector Pin Assignments
Table 36 (Page 2 of 2). Pin Assignments for the ISA Bus Connectors
Pin Signal Name I/O Pin Signal Name I/O
B29 +5 V dc NA A29 SA2 I/O
B30 OSC O A30 SA1 I/O
B31 Ground NA A31 SA0 I/O
D1 MEMCS16# I C1 SBHE# I/O
D2 IOCS16# I C2 LA23 I/O
D3 IRQ10 I C3 LA22 I/O
D4 IRQ11 I C4 LA21 I/O
D5 IRQ12 I C5 LA20 I/O
D6 IRQ15 I C6 LA19 I/O
D7 IRQ14 I C7 LA18 I/O
D8 DACK0# O C8 LA17 I/O
D9 DRQ0 I C9 MEMR# I/O
D10 DACK5# O C10 MEMW# I/O
D11 DRQ5 I C11 SD8 I/O
D12 DACK6# O C12 SD9 I/O
D13 DRQ6 I C13 SD10 I/O
D14 DACK7# O C14 SD11 I/O
D15 DRQ7 I C15 SD12 I/O
D16 +5 V dc NA C16 SD13 I/O
D17 MASTER# I C17 SD14 I/O
D18 Ground NA C18 SD15 I/O
Appendix A. Connector Pin Assignments 37
