Appendix A. Connector Pin Assignments
* This reserved pin should be connected to Ground
Table 38 (Page 2 of 2). Pin Assignments for the AGP
Bus Connector
Pin Signal Name Pin Signal Name
A34 Vddq 3.3 B34 Vddq 3.3
A35 AD22 B35 AD21
A36 AD20 B36 AD19
A37 Ground B37 Ground
A38 AD18 B38 AD17
A39 AD16 B39 C/BE2#
A40 Vddq 3.3 B40 Vddq 3.3
A41 FRAME# B41 IRDY#
A42 Spare B42 Spare
A43 Ground B43 Ground
A44 Spare B44 Spare
A45 VCC 3.3 B45 VCC 3.3
A46 TRDY# B46 DEVSEL#
A47 STOP# B47 Vddq 3.3
A48 Spare B48 PERR#
A49 Ground B49 Ground
A50 PAR B50 SERR#
A51 AD15 B51 C/BE1#
A52 Vddq 3.3 B52 Vddq 3.3
A53 AD13 B53 AD14
A54 AD11 B54 AD12
A55 Ground B55 Ground
A56 AD9 B56 AD10
A57 C/BE0# B57 AD8
A58 Vddq 3.3 B58 Vddq 3.3
A59 Reserved B59 AD STB0
A60 AD6 B60 AD7
A61 Ground B61 Ground
A62 AD4 B62 AD5
A63 AD2 B63 AD3
A64 Vddq 3.3 B64 Vddq 3.3
A65 AD0 B65 AD1
A66 SMB1 B66 SMB0
Appendix A. Connector Pin Assignments 41
