Appendix A. Connector Pin Assignments
Note: All inputs and outputs are with respect to the system board.
Table 48. Pin Assignments for the Monitor Connector
Pin Signal Name I/O
1 Red O
2 Green O
3 Blue O
4 Monitor ID2 - not used I
5 Ground NA
6 Red ground NA
7 Green ground NA
8 Blue ground NA
9 +5 V, used by DDC2B NA
10 Ground NA
11 Monitor ID 0 - not used I
12 DDC2B serial data I/O
13 Horizontal sync. O
14 Vertical sync. O
15 DDC2B clock I/O
Appendix A. Connector Pin Assignments 51
