This ends the procedure.
2.
The failing air moving device is in a secondary expansion unit. Find the unit reference code in the
following tables to determine the failing AMD and part number. Then, see Locations and addresses for
the unit you are working on to determine the location of the failing item.
For Migrated towers, refer to the Migrated Expansion Tower Problem Analysis, Repair and Parts
manual on the V5R1 Supplemental Manuals web site
for locations and part number information.
Table 8. For FC 503x
Unit reference code FRU
2240 Air moving device (AMD) panel
2241F AMD 1
2242 AMD 2
2244
v AMD 1 (if fan 4 is not installed)
v Distribution Cable (part 44H8337)
2245 AMD 5
2246 AMD 6A (SPD enclosure)
2246 AMD 6B (PCI enclosure)
Table 9. For FC 5065, FC 5066 I/O frame
Unit reference code FRU
7610, 8610 AMD B01
7620, 8620 AMD B02
Table 10. For FC 5072, 5073, 5077, 5082, 5083 frames
Unit reference code FRU
7000 ACMODUL (see “ACMODUL” on page 268 for part number)
7001 AMD 1
7002 AMD 2
7003 AMD 3
7004 AMD 4
Table 11. For FC 5074, 5079, FC 5094, FC 5294, FC 5294, FC 8093-002, FC 8094-002, I/O frame
Unit reference code FRU
7610, 7611, 8610 AMD B01
7620, 7621, 8620 AMD B02
Table 12. For FC 5075
Unit reference code FRU
7610, 7611 AMD B01
7620, 7621 AMD B02
Analyze hardware problems 273
