IBM iSeries 270 Hardware Problem Analysis And Isolation

Decimal
loop
number
Hexadecimal
loop number
System
model NIC’s FRU position
HSL port labels on system unit
or processor tower
258 0102 825 MB1 HSL ports C0 and C1.
Table 12. Loop number to NIC port location labels for Models 830/SB2, 840/SB3, 870, and 890
Decimal
loop
number
Hexadecimal
loop number
System
model
NIC’s FRU
position HSL port labels on system unit or processor tower
256 0100 830 and SB2 M06
v ″A0″ located in the primary I/O unit on the HSL I/O
bridge card in position C08.
v ″A1″ located on the back of the primary I/O unit
under the NIC’s FRU.
256 0100 840 and SB3 M17 ″A0″ and ″A1″ on the NIC card in position M17
256 0100 Models 870
and 890
M41 ″C0″ and ″C1″ on the NIC card in position M41
257 0101 830 and SB2 M06 ″B0″ and ″B1″ located on the NIC card in position
M06
257 0101 840 and SB3 M17 ″B0″ and ″B1″ located on the NIC card in position
M17
257 0101 Models 870
and 890
M41 ″D0″ and ″D1″ located on the NIC card in position
M41
258 0102 830 and SB2 M06 ″C0″ and ″C1″ on the NIC card in position M06
258 0102 840 and SB3 M17 ″C0″ and ″C1″ on the NIC card in position M17
258 0102 Models 870
and 890
M40 ″A0″ and ″A1″ on the NIC card in position M40
259 0103 830 and SB3 M06 ″D0″ and ″D1″ on the NIC card in position M06
259 0103 840 and SB3 M17 ″D0″ and ″D1″ on the on the NIC card in position M17
259 0103 Models 870
and 890
M40 ″B0″ and ″B1″ on the NIC card in position M40
260 0104 840 and SB3 M17 ″E0″ and ″E1″ on the NIC card in position M17
260 0104 Models 870
and 890
M30 ″C0″ and ″C1″ on the NIC card in position M30
261 0105 840 and SB3 M17 ″F0″ and ″F1″ on the NIC card in position M17
261 0105 Models 870
and 890
M30 ″D0″ and ″D1″ on the NIC card in position M30
262 0106 840 and SB3 M17 ″G0″ and ″G1″ on the NIC card in position M17
262 0106 Models 870
and 890
M39 ″A0″ and ″A1″ on the NIC card in position M39
263 0107 840 and SB3 M17 ″H0″ and ″H1″ on the NIC card in position M17
263 0107 Models 870
and 890
M39 ″B0″ and ″B1″ on the NIC card in position M39
264 0108 Models 870
and 890
M40 ″C0″ and ″C1″ on the NIC card in position M40
265 0109 Models 870
and 890
M40 ″D0″ and ″D1″ on the NIC card in position M40
Analyze hardware problems 73
