6. Multi-adapter bridge domains are labeled ″PCI Bridge Set″ inside the tower.
7. The following table provides information necessary to identify the IOP to which IOAs are assigned.
v The left column indicates the domain in which IOA assignment is allowed.
v The right column is used to determine the IOP to which an IOA is assigned.
v The first position in the list must be an IOP. The remaining positions may be IOPs or IOAs. IOAs are
assigned to the first IOP located to their left in the list. Although IOAs can be manually reassigned
using SST/DST, the IOA assignments return to the default order after each IPL.
Table 1. IOA assignment rules
Multi-adapter bridge domain / PCI bridge set IOA assignment rules
MB1, C01 - C06 MB1, C06, C05, C04, C03, C02, C01
C07 - C12 C12, C11, C10, C09, C08, C07
Table 2. FRU locations and failing components for Model 820
Position FRU name
Possible failing
component
Type, CCIN, or part number
(use the Type, model, and
part number list to
determine the part number
when the type or CCIN are
given.)
Remove and replace/recovery
procedure
C01 PCI card
1. IOP
2. IOA
See the Type, model, and part
number list
Go to Model 820 - Cards -
Concurrent.
C02 PCI card (Short
if 2890 IXS in
C04)
1. IOP
2. IOA
See the Type, model, and part
number list
Go to Model 820 - Cards -
Concurrent.
C03 PCI card (if no
IXS in C04)
1. IOP
2. IOA
See the Type, model, and part
number list
Go to Model 820 - Cards -
Concurrent.
C04 PCI card
1. Integrated
xSeries
(TM)
Server (IXS)
2. IOP
3. IOA
1. CCIN is 2890 (See page
527) or 2892 (See page
527)
2. CCIN is 2842 (See page
527), 2843 (See page
527), or 2844 (See page
527)
3. See the Type, model, and
part number list
Go to Model 820 - Cards -
Concurrent.
C05 PCI card IOA See the Type, model, and part
number list
Go to Model 820 - Cards -
Concurrent.
C06 PCI card
1. IOP
2. IOA
1. CCIN is 2842 (See page
527), 2843 (See page
527), or 2844 (See page
527)
2. See the Type, model, and
part number list
Go to Model 820 - Cards -
Concurrent.
250 Hardware (Remove and Replace; Part Locations and Listings)
