IBM iSeries 270 Service Manual

Position
Possible
failing item DSA (BBBBCcbb) Unit address
D19 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″R-2″.
x10600FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D20 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″R-2″.
x10700FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D21 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″L-1″.
x20300FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D22 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″L-1″.
x20400FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D23 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″L-1″.
x20500FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D24 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″L-1″.
x20600FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D25 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″L-1″.
x20700FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D26 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″R-2″.
x20300FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D27 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″R-2″.
x20400FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D28 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″R-2″.
x20500FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D29 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″R-2″.
x20600FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D30 Disk unit The disk unit has the same DSA as the
IOA attached to the internal cable
labelled ″R-2″.
x20700FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D31 Disk unit The disk unit has the same DSA as the
IOA attached to the internal flat ribbon
cable.
x00100FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D32 Disk unit The disk unit has the same DSA as the
IOA attached to the internal flat ribbon
cable.
x00200FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D33 Disk unit The disk unit has the same DSA as the
IOA attached to the internal flat ribbon
cable.
x00300FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D34 Disk unit The disk unit has the same DSA as the
IOA attached to the internal flat ribbon
cable.
x00400FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
D35 Disk unit The disk unit has the same DSA as the
IOA attached to the internal flat ribbon
cable.
x00500FF (where x is the same as
the first character of the xFFFFFFF
IOA Unit Address)
348 Hardware (Remove and Replace; Part Locations and Listings)
