T
able
2.
Final
assembly
-
Models
270,
800,
and
810,
(continued)
Index
Part
Number
Units
Description
14
16G8095
1
T
ime
of
day
battery
15
NONUM
1
Backplane
assembly
16
75G2878
19
Screw
,
M3.5
x
8mm
17
24L1747
1
Plenum
air
flow
18
75G2878
1
Screw
,
M3.5
x
8mm
19
NONUM
1
Plenum
air
flow
20
NONUM
1
Plenum
air
flow
Analyze
hardware
problems
371
382
384
