Index Part number Units Description
6 21P4612 1 Cover assembly, front (Domino iSeries)
Final assembly - Model 820: For use by authorized service providers.
Table 1. Final assembly - Model 820
Index Part number Units Description
1 NONUM AR Filler plate, air moving device (AMD)
2 24L1730 AR Air moving device (AMD) assembly
3 24L1737 1 Plenum air flow
4 24L1546 1 CEC assembly, processor / memory
5 75G2878 2 Screw, M3.5 x 8mm
6 1622678 6 Screw
380 Hardware (Remove and Replace; Part Locations and Listings)
