Index Part number Units Description
26 1621816 6 Screw
27 16G8095 1 Time of day (TOD) battery
28
v 97H7307 (FC 5074)
v 53P6023 (FC 5094)
1 PCI card cage assembly
29 1621811 6 Screw, M4 (10mm)
Note: This only applies to the FC 5074.
Figure 5. Final assembly — FC 5094
Table 5. Final assembly — FC 5094
Index Part number Units Description
30 53P5259 1 Power sub frame assembly for dual line cord
31 1621811 8 Screw, M4 (10mm)
32 24L0940 2 Filler, spacer
33 1621811 2 Screw, M4 (10mm)
34 24L0939 2 Filler, power supply
35 1621811 4 Screw, M4 (10mm)
Analyze hardware problems 461
