Page #81 background imageLoading...
Page #81 background image
Bus number
Multi-adapter bridge
number in DSA
Multi-adapter bridge
function number in
DSA Item DSA points to:
Position label and
PCI data width
v 0002 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 2 PCI IOP or IOA card C06
v 0002 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 3 PCI IOP or IOA card C07
v 0002 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 4 and 5 PCI IOP or IOA card C08
v 0002 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 6 and 7 IOA card C09
v 0002 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 F Multi-adapter bridge CB1
v 0003 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 0 and 1 PCI IOP or IOA card C11
v 0003 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 2 PCI IOP or IOA card C12
Analyze hardware problems 69
