Bus number
Multi-adapter bridge
number in DSA
Multi-adapter bridge
function number in
DSA Item DSA points to:
Position label and
PCI data width
v 0003 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 3 PCI IOP or IOA card C13
v 0003 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 4 and 5 PCI IOP or IOA card C14
v 0003 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 6 and 7 IOA card C14
v 0003 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 F Multi-adapter bridge CB1
Table 7. Card positions for FC 5074, 5079 I/O Expansion Towers, and FC 5078/0578 PCI Expansion
Unit (for FC 5079 see Servicing notes (See page 65) above)
Bus number
Multi-adapter
bridge
number in
DSA
Multi-adapter
bridge function
number in DSA Item DSA points to:
Position label and PCI
data width
xxxx (assigned by LIC) 1 0 PCI IOP or IOA card C01 (64 bit)
xxxx (assigned by LIC) 1 2 PCI IOP or IOA card C02 (64 bit)
xxxx (assigned by LIC) 1 4 PCI IOP or IOA card C03 (64 bit)
xxxx (assigned by LIC) 1 6 PCI IOP or IOA card C04 (64 bit)
xxxx (assigned by LIC) 1 F PCI IOP or IOA card CB1
xxxx (assigned by LIC) 1 0 PCI IOP or IOA card C05 (64 bit/INS)
xxxx (assigned by LIC) 1 2 PCI IOP or IOA card C06 (32 bit)
xxxx (assigned by LIC) 1 3 PCI IOP or IOA card C07 (32 bit)
xxxx (assigned by LIC) 1 4 PCI IOP or IOA card C09 (64 bit)
xxxx (assigned by LIC) 1 6 PCI IOP or IOA card C10 (64 bit)
xxxx (assigned by LIC) 1 F Multi-adapter bridge CB1
70 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and Isolation
